Which carries the Intel dual- core 1.86GHz Atom AMB-D255T1

 AMB-D255T1, which carries the Intel dual- core 1.86GHz Atom Processor D2550. AMB-D255T1 features powerful graphic performance via VGA and HDMI, DDR3 SO-DIMM support, mSATA socket with USB signals and SIM slot, and a DC jack for easy power in. AMB-D255T1 also provides complete I/O such as 4 x COM ports, 6 x USB2.0 ports, 1 x GbE RJ-45 port, 1 x SATA port with power connector.

AMB-D255T1 can support dual displays via VGA, HDMI or LVDS. AMB-D255T1 has one MiniPCIe type expansion slot with SIM card socket for customer’s expansion. This expansion slot works with SATA and USB signals that can be equipped with mSATA storage module, Wi-Fi module, or 3G/4G telecommunication module.

embedded system, in vehicle PC, Industrial PC

Low Power Fanless Processing VIA Eden™ Chipset

Fanless embedded system, in vehicle computer, Industrial PC

VIA Eden processors are scalable from 400MHz to 1.5GHz all within a maximum thermal envelope of 7.5 watts, and are available with a diverse range of feature sets that enable PC functionality and connectivity from traditionally single function devices.

The VIA Eden processor family is available in nanoBGA, nanoBGA2 and EBGA packaging, using 150nm, 130nm and the latest 90nm SOI manufacturing process to deliver leading performance per watt and in fully RoHS compliant packages.



from

http://www.via.com.tw/en/products/processors/eden/

Acrosser Vehicle products Architecture

Fanless embedded system, in vehicle computer, Industrial PC

To reduce labor cost and self services become more popular and acceptable, by Kiosk, a lot of product information, sales and service can be achieved with low cost and non-interrupted supply.

 Except mutual interactive information providing, Kiosk (or ATM) also can be used for cash billing, ticketing, airplane electronic ticket re-confirm, Photo printing and other functions operating 24 hours as non-stop service.

It provides much more conveniences to consumers Digital signage has wide application, except providing new product information and commercial advertisement broadcast, there are also integration application combine Digital signage and Kiosk, through a mutual interactive method offer end user new information experience.
For these applications, Acrosser provides variety of solutions from SBC, embedded system to HMI and Panel PC for customer to fit in all kind of application they required. Our HMI / Panel PC provides high quality and stability as for Kiosk / ATM platform. For outdoor application, Acroser’s dust-proof, anti-shock, fanless embedded system solution fits most of application demands and enviroments.

Great AR-V6005 and AR-V6100 Win Taiwan Excellence

embedded system, in vehicle pc, Industrial PC
embedded system, in vehicle pc, Industrial PC

Both Acrosser In-Vehicle PC, AR-V6100 & AR-V6005 have been selected as the winner of 21th Taiwan Excellence Award. This award delivered by the Ministry of Economic Affairs (MOEA) and Taiwan External Trade Development Council (TAITRA), to encourage Taiwan industries to upgrade and incorporate innovations into their new products. ACROSSER has launched the Great AR-V6005 and AR-V6100 in 2012. To make your business smarter and more effective, Acrosser In-Vehicle solution is the best choice for you. For more information, please visit www.acrosser.com or contact ACROSSER Technology, ACROSSER USA, and ACROSSER worldwide resellers in your local area.

More powerful graphic performance AMB-N280S1

embedded system, in vehicle computer, Industrial PC
embedded systems, gaming platform, single board computer

 AMB-N280S1 can support both two displays to maximum resolution 1920 x 1200. It also offers the 18-bit LVDS interface for small size LCD panel.

AMB-N280S1 Features

‧ Intel Atom N2800 1.86GHz
‧ 1 x DDR3 SO-DIMM up to 4GB
‧ 1 x VGA
‧ 1 x HDMI
‧ 1 x 18-bit LVDS
‧ 4 x USB2.0
‧ 6 x COM (5 x RS-232, 1 x RS-232/485)
‧ 2 x GbE (Realtek RTL8111E)
‧ 1 x KB/MS
‧ 1 x Mini-PCIe slots
‧ 1 x SATA
‧ 8-bit GPIO

In-vehicle computers for entry-level and applications

AR-V6005FL is equipped with Intel Atom E640 processor and Intel EG20T PCH chipset for low power consumption and entry-level vehicle applications.

AR-V6100FL is embedded with Intel HM65 chipset and FC988PGA socket to support Intel Core i7 2710QE/i5 2510E/i3 2330E/ Celeron B810 processor. Based on Intel powerful 2nd Generation Sandy Bridge Core i CPU , AR-V6100FL is a powerful industrial-grade computing solution for all vehicle application, such as Fleet management, vision procession, Telemetric, Traffic safety control and numerous other vehicles. To use in rugged environment, AR-V6100FL is capable of operation at -20°C to 60°C and can withstand vibration up to 2G (follow IEC60068-2-64) and shock up to 50G 11ms (follow IEC60068-2-27).

AR-V6005FL and AR-V6100FL in vehicle computers are both with the power subsystem can be fully protected by over-voltage, over-current and surge protection which make them comply with E-Mark and ISO-7637 in-vehicle power standard.
